Double Beam UV VIS Spectrophotometer

Double Beam UV VIS Spectrophotometer Specification

Usage
Industrial

Size
Standard

Product Type
Double Beam UV VIS Spectrophotometer

Equipment Type
Spectrophotometer

Color
White

Material
Mild Steel

Application
Laboratory

Warranty
1 Year

Double Beam UV VIS Spectrophotometer Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About Double Beam UV VIS Spectrophotometer

UV SPECTROPHOTOMETER: Double Beam MODEL 2802

Wavelength Range: 190.. 1100 nm

Spectral Bandwidth: 1 nm

Optical System : Double Beam, Grating 1200 lines/mm

Wavelength Accuracy: +/- 0.3nm

Wavelength Re peatability: 0.2nm

Photometric Accuracy: +/-0.3 %T

Photometric Rep eatability: 0.2%T

Photometric Range: -0.3 to 3A, 0 to 200%T, 0-9999C

Stray Light : +/- 0.05 % T @220nm,360nm

Stability : +/- 0.001 %A/h @500nm

Display : 320 X 240 Dots Graphical LCD

Baseline Flatness : +/- 0.002A

Sample Compartment: 8 C ll Cuvette Holder.

Light Source : Halogen & Deuterium Lamp ( Pre aligned)

Out Put : USB Port & Parallel Port ( Printer)

Power Requirement : 230V AC 50Hz.

Packing Dimensions: ( WxDxH) : 860 x 660x465 mm

Weight: 26 Kg

Advanced Double Beam Technology

Our Double Beam UV VIS Spectrophotometer utilizes state-of-the-art optical technology for accurate and simultaneous comparison of sample and reference, enhancing measurement reliability for laboratory and industrial applications. This configuration minimizes measurement errors and improves stability, making it suitable for sophisticated analytical work.

Robust Construction and Efficient Operation

Built from high-grade mild steel, this spectrophotometer is designed to withstand rigorous laboratory conditions. Its user-friendly interface and standard size make it adaptable to different workspace requirements, ensuring ease of maintenance and long operational life.

FAQ's of Double Beam UV VIS Spectrophotometer:

Q: How does a Double Beam UV VIS Spectrophotometer operate?

A: A Double Beam UV VIS Spectrophotometer works by splitting the light source into two beams - one passes through the sample and the other through a reference. By comparing the absorbance or transmittance of both beams, it provides accurate spectral data, minimizing disturbances caused by fluctuations in the light source.

Q: What are the key benefits of using a Double Beam UV VIS Spectrophotometer in laboratories?

A: This instrument offers superior accuracy and stability due to simultaneous dual-beam measurement. Its robust mild steel construction ensures durability, while the standard size and convenient design make it a versatile choice for various laboratory and industrial applications.

Q: Where can this spectrophotometer be effectively used?

A: The Double Beam UV VIS Spectrophotometer is extensively utilized in laboratories, research centers, industrial quality control, and educational institutions for both qualitative and quantitative analysis in chemistry, biology, pharmaceuticals, and environmental testing.

Q: When should I consider routine maintenance for this equipment?

A: Regular maintenance is recommended every six to twelve months, depending on the frequency of use. This includes calibration, optical checks, and cleaning to ensure consistent performance and accurate results.

Q: What is the process for obtaining after-sales support and warranty service?

A: As both manufacturer and service provider, we offer a comprehensive one-year warranty. Customers can contact our support team in India for troubleshooting, repairs, or replacement of any defective components during the warranty period.

Q: How can I use this spectrophotometer for industrial applications?

A: To utilize the spectrophotometer in industrial settings, place it in a controlled environment, calibrate the instrument according to your sample type, and follow the operation manual to conduct absorption or transmittance analysis for quality assurance or research purposes.
